Dimensions
Width: 30" (76.2 cm)Height: 3.37" (8.6 cm)Depth: 21" (53.3 cm)
Shipping Dimensions
Width: 34.81" (88.4 cm)Height: 12.06" (30.6 cm)Depth: 25" (63.5 cm)
Weight
60.00 lbs (27.2 kg))
Key Features:
- Even-Heat Technology
- Professional Dual-Ring Burner
- CookShield Finish
- Electronic Ignition
- Full-Width Cast-Iron Grates
- Lighted Control Knobs
Even-Heat Technology
Effortlessly melt butter or simmer sauces with KitchenAid’s Even-Heat technology. A diffuser plate allows for more control of the cooktop flame at its lowest setting, ensuring more precise melting and simmering.
Professional Dual-Ring Burner
Quickly go from one small flame for precise simmering to a dual flame for powerful boiling, all on the same burner.
CookShield Finish
The finish on this cooktop helps protect it from spills and stains that may occur with high-temperature cooking. This permanent finish makes it easy to wipe your cooktop clean without harsh chemicals to help it look cleaner and brighter longer.
Electronic Ignition
This cooktop’s electronic ignition automatically lights the burners, so no standing pilot light is required.
Full-Width Cast-Iron Grates
This cooktop’s cast-iron grates not only enhance its modern look, they also allow for easy movement of cookware around the entire cooking surface.
Lighted Control Knobs
The lighted control knobs deliver a premium look and feel that reflects the high quality of the cooktop, while letting you know when a burner is in use.
Detailed Specifications
- Burner Style: Sealed Gas
- Cut-Out Depth: 19"
- Cut-Out Width: 28.9"
- Fuel Type: Gas
- Heating Element On Indicator Light
- Installation: Over Built-In Oven
- Number of Burners: 5
- Surface Material: Stainless Steel
- Centre Rear Type: Professional Dual Tier
- Centre Rear Power: 17,000 BTU
- Left Front Type: Burner
- Left Front Power: 10,000 BTU
- Left Rear Type: Simmer
- Left Rear Power: 6,000 BTU
- Right Front Type: Even-Heat Torch Burner
- Right Front Power: 10,000 BTU
- Right Rear Type: Burner
- Right Rear Power: 7,000 BTU
- Type: Standard
